Accurate bed made from cast aluminiumSpindle made from diecast aluminiumSpeed range of 500-5000rpmHeadstock suibtable to take ER11 colletsTailstock has a MK0/short boreQuick change tool post for 6mm toolingThe Proxxon FD150/E is a compact metal working lathe for facing and longitudinal turning, boring, taper turning, parting and drilling. The high maximum speed (5000rpm) allows very small diameters to be machined. The lathe has an accurate bed made from cast aluminium and the spindle from diecast aluminium. It is run using a powerful, quiet running DC motor which has a two stage belt drive used in conjunction with an electronic speed control to achieve the full speed range (500-5000rpm). The main spindle runs with precision bearings and has a continuous bore of 8.5mm. A three jaw self-centring chuck is supplied with an inside jaw range of 1.5-32mm and 12-65mm outside. The tailstock comes with a live centre and has an MK0/short bore. There is a quick change tool post with the machine accepting 6mm tooling.Specification for Proxxon FD 150/E Lathe:Cross Slide Travel (X) 40mm, (Z) 60mmDistance Between Centres 150mmHeight Over Cross Slide 33mmModel FD 150/ENett Weight 4.5kgOverall L x W x H 360 x 150 x 150mmSpeed Range 500 – 5000rpmSpindle Bore 8.5mmSpindle Speed MK0/short bore
